Nylon 6 vs. Nylon 66: Properties, Applications and Differences

NYLON

Nylon is a group of synthetic polymers known as polyamides, and it is commonly used in various extrusion processes due to its excellent mechanical properties, heat resistance, and chemical resistance. Nylon is versatile and finds applications in industries ranging from textiles and engineering to packaging and film production. Making nylon involves a chemical synthesis process called polycondensation, where two monomers, diamine and dicarboxylic acid, are reacted to form long-chain nylon molecules.

Formula of nylon: (C6 H6 N O) n

Nylon 6 and Nylon 66

NYLON 6:

Nylon 6, also known as polyamide 6, is one of the most widely used types of nylon for blown film extrusion. Blown film extrusion is a process used to manufacture thin plastic films with various properties, such as thickness, strength, and flexibility. In this process, molten plastic is extruded through a circular die to form a tube-like structure, which is then inflated and stretched to achieve the desired dimensions.
The manufacturing of nylon 6 involves a series of steps known as the nylon polymerization process.

How Nylon 6 is commonly manufactured

Raw Material Preparation:

• The primary raw material for Nylon 6 is caprolactam, which is derived from crude oil or natural gas. Caprolactam is a cyclic amide with six carbon atoms in its molecular structure.

Charging the Reactor:

• Caprolactam is charged into a reactor vessel equipped with agitation systems and temperature controls. The reactor is often sealed to prevent the escape of any volatile components during the process.

Initiating the Polymerization:

• To initiate the polymerization reaction, a catalyst is added to the caprolactam. The catalyst helps break the cyclic structure of caprolactam and activates the polymerization process.

Heating and Polymerization:

• The reactor is heated to a specific temperature, usually around 230°C to 260°C (446°F to 500°F). At this elevated temperature, the caprolactam monomers undergo a ring-opening polymerization reaction. The amide groups in the caprolactam molecules react with each other to form long chains of nylon 6.

Solidification and cooling:

• As the polymerization reaction progresses, the molten nylon 6 material solidifies into a semi-crystalline state. The reaction is allowed to continue until the desired molecular weight and properties of the nylon are achieved.

Pelletizing:

• Once the polymerization is complete, the nylon 6 material is cooled and then cut into small pellets or chips. These nylon pellets are the final product and serve as the raw material for various manufacturing processes.

Drying:

• Nylon 6 pellets have a high affinity for moisture, so they are carefully dried to remove any moisture content. This drying step is essential to prevent issues with the final product’s quality and properties.

Difference Between Nylon 6 and Nylon 66

Properties:

Nylon Extrusion Process:

The nylon extrusion process involves melting nylon resin pellets and then forcing the molten material through a die to create a continuous profile, such as a rod, tube, sheet, or film. The process can be carried out using various types of extrusion machines, depending on the specific application and desired product.
Here’s an overview of the nylon extrusion process:

Raw Material Preparation:

The first step in the nylon extrusion process is the preparation of the raw material. Nylon resin is typically supplied in the form of pellets or granules. These pellets are pre-dried to remove any moisture content, as nylon is sensitive to moisture, which can affect the quality of the extruded product.

Feeding the Resin:

The pre-dried nylon pellets are fed into the hopper of the extruder machine. The hopper feeds the resin into the barrel of the extruder.

Melting and Plasticization:

Inside the barrel of the extruder, the nylon pellets are heated and gradually melted by the use of electric heaters and/or frictional heat generated by the rotating screw. The rotating screw also conveys the molten nylon material forward and helps in achieving uniform melting.

Pressure Buildup and Homogenization:

As the molten nylon moves along the barrel, the pressure within the extruder increases due to the restricted flow path. This pressure buildup helps in achieving a homogenous melt with consistent properties.

Filtration:

In some cases, a filtration system may be employed to remove any contaminants or impurities present in the molten nylon before it enters the die. This step ensures that the final product is of high quality.

Die Design and Extrusion:

The die is a specially designed tool with an opening or series of openings that determine the shape and dimensions of the extruded nylon product. The molten nylon is forced through the die, taking the shape of the desired profile.

Cooling and Sizing:

As the nylon emerges from the die, it is rapidly cooled using air- or water-cooling systems. The cooling process solidifies the molten nylon into a solid shape, maintaining the desired profile and dimensions.
